Hand-Held Laser Scanner Port 11-7
Beep After Good Decode
This parameter affects the hand-held scanner only. When enabled, the scanner connects to the Scanner port beeps after a successful
decode.
Beep After Good Decode
This parameter affects the hand-held scanner only. When disabled, the scanner connected to the Scanner port does not beep after a
successful decode. Beeps for parameter menu scanning and serial communications are not affected.
Do Not Beep After Good Decode
